IoT Your Way with a Custom Gateway!
Gateworks Corporation is a leading supplier of made in the USA industrial grade ARM based SBCs that can be used to implement high performance IoT Gateway solutions. Many IoT applications require rugged, industrial temperature rated hardware which is where Gateworks SBCs excel. Gateworks SBC’s feature Mini-PCIe expansion slots which allow support of a variety of wireless standards such as Cellular (LTE/CATM1), WiFi, Bluetooth, SubGHz, Thread, WiSun, Zigbee LoRa, SigFox and Satellite. The Mini-PCIe slots provide customers with a flexible plug-n-play platform that can be tailored to meet their exact specifications. Gateworks SBCs also include GPIO, USB, CAN, RS232, RS485, SPI and I2C interfaces for connecting local sensors. Single, dual and 5-port Ethernet models are also available including SFP Fiber support.
All boards support an Open Source Linux OS (Ubuntu, OpenWrt) which provides the user with complete access and control of the data and allows the use of any of the large number of cloud providers such as Microsoft Azure and Amazon Web Service (AWS). Many different methods can be used to connect to the cloud, including standard WiFi, Ethernet, Iridium Satellite and Cellular.
Gateworks can also provide customers with a “Special” configuration of our standard products. This “Special” program allows customers to create cost and feature optimized versions of our standard products. The special is assigned a unique, revision locked, part number so customers can be insured they receive the same exact configuration every time they order. Note there is a 100-piece minimum order quantity for special configuration models. Some of the items that can be configured under the “Specials” program are:
- Changing components such as DRAM size, Flash size, or CPU type/speed
- Removing components not used to lower the cost of the product
- Adding optional components designed into the product but not loaded on the standard version (ie. locking headers)
- Programming the customer firmware
For high volume applications, Gateworks can also design a full custom SBC to meet the customer exact needs. Contact email@example.com for more information and to discuss your exact needs.
Recommended products for building your custom IoT Gateway.
Recommended Single Board Computers:
- Venice GW7100 – Small 35mm x 100mm, 1x Mini-PCIe sites, 1x GbE, i.MX8M Mini Quad Core CPU
- Venice GW7200 – 70mm x 100mm, 2x Mini-PCIe sites, 2x GbE, i.MX8M Mini Quad Core CPU
- Venice GW7300 – 105mm x 100mm, 3x Mini-PCIe sites, 2x GbE, i.MX8M Mini Quad Core CPU
- Ventana GW5220 – Small 70mm x 100mm, 2x Mini-PCIe sites, 1x GbE, i.MX6 Dual Core CPU
- Ventana GW5913 – Small 35mm x 100mm, 1x Mini-PCIe sites, 1x GbE, i.MX6 Dual Core CPU
- Ventana GW5910 – Small 70mm x 100mm, 2x Mini-PCIe sites, 1x GbE, WiFi/BLE, SubGHz Radio Onboard, i.MX6 Dual Core CPU
- Additional Ventana and Newport SBCs available in a variety of form factors and with up to 6x Mini-PCIe sites. See here for more information.
Recommended Mini-PCIe Cards for Wireless Support:
- GW16146 802.11ah HaLow WiFi Radio – Sub 1GHz 802.11ah HaLow, using IP protocol for long range and large quantity of nodes
- GW16122 SubGHz Radio – Based on Ti CC1352P Multiprotocol MCU
- GW16132 LTE CATM1 Cellular & BLE 5.0 Radio – Based on ublox SARA-R410 CATM1 Cellular Module and NINA-B301 BLE module (Nordic nRF52840 chipset)
- GW16130 Iridium SBD Satellite Radio – Based on Iridium 9603N SBD Module
- GW17032 802.11ac/abgn WiFi Radio – Based on Qualcomm QCA9880 Chipset, 3×3 MIMO
- GW17039 802.11bgn+BLE 4.0 Radio – Based on Qualcomm AR9565 Chipset
- GW17046 LTE CAT4 Cellular Radio – Based on ublox Toby-L2 Module
- Additional 3rd Party Radios are Available for Support of other Wireless Standards such as LoRa and SigFox.
