Factory Automation & Communication
Gateworks Corporation is a leading supplier of industrial grade ARM based SBCs that can be used to implement high performance smart factory solutions. Many factory applications require rugged, industrial temperature rated hardware which is where Gateworks SBCs excel. These SBCs are Made in the USA which result in a high quality and robust product.
Wireless and Wired Communication
Gateworks SBC’s feature Mini-PCIe expansion slots which allow support of a variety of wireless standards such as Cellular (LTE/CATM1), WiFi, Bluetooth, SubGHz, Thread, WiSun, Zigbee LoRa, SigFox and Satellite. The Mini-PCIe slots provide customers with a flexible plug-n-play platform that can be tailored to meet their exact specifications. Different wireless standards support important factory modes, such as mesh and point to point networking.
Single, dual and 5-port Gigabit Ethernet models are available including SFP Fiber support.
Machine Learning & Recognition
Gateworks SBCs can act as as platform for certain machine learning applications utilizing things such as a tensor processing unit (TPU) to detect machine abnormalities and patterns. Camera recognition can also be implemented through the TPU. The TPU device would interface through one of the high-speed Mini-PCIe slots.
Sensors play a crucial role in indicating the health of a factory. These may include temperature, humidity, motion, vibration and infrared. Gateworks SBCs include GPIO, USB, CAN, RS232, RS485, SPI and I2C interfaces for connecting local sensors.
Bluetooth Low Energy has become extremely popular for interfacing to sensors wirelessly. This sensor data can then be stored and analyzed locally on the Gateworks SBC or pushed up to a cloud server for more long term storage and heavier analysis.
RFID can also be utilized for tracking and monitoring things such as equipment and assets.A RFID system can typically be integrated with the Gateworks SBC through the Mini-PCIe slot. A common industrial solution can be found through companies such as Impinj.
All boards support an Open Source Linux OS (Ubuntu, OpenWrt) which provides the user with complete access and control of the data and allows the use of any of the large number of cloud providers such as Microsoft Azure and Amazon Web Service (AWS).
Gateworks can also provide customers with a “Special” configuration of our standard products. This “Special” program allows customers to create cost and feature optimized versions of our standard products. The special is assigned a unique, revision locked, part number so customers can be insured they receive the same exact configuration every time they order. Note there is a 100-piece minimum order quantity for special configuration models. Some of the items that can be configured under the “Specials” program are:
- Changing components such as DRAM size, Flash size, or CPU type/speed
- Removing components not used to lower the cost of the product
- Adding optional components designed into the product but not loaded on the standard version (ie. locking headers)
- Programming the customer firmware
For high volume applications, Gateworks can also design a full custom SBC to meet the customer exact needs. Contact email@example.com for more information and to discuss your exact needs.
Recommended products for Factory Automation and Communication
Recommended Single Board Computers:
- Ventana GW5220 – Small 70mm x 100mm, 2x Mini-PCIe sites, 1x GbE, i.MX6 Dual Core CPU
- Ventana GW5913 – Small 35mm x 100mm, 1x Mini-PCIe sites, 1x GbE, i.MX6 Dual Core CPU
- Ventana GW5910 – Small 70mm x 100mm, 2x Mini-PCIe sites, 1x GbE, WiFi/BLE, SubGHz Radio Onboard, i.MX6 Dual Core CPU
- Ventana GW5510 – Small 35mm x 70mm, 1x Mini-PCIe sites, i.MX6 Single Core CPU
- Newport GW6100 – Small 35mm x 100mm, 1x Mini-PCIe sites, 1x GbE, OcteonTx Dual Core CPU
- Newport GW6200 – Small 70mm x 100mm, 2x Mini-PCIe sites, 2x GbE, OcteonTx Dual Core CPU
- Newport GW6400 – 140mm x 100mm, 4x Mini-PCIe sites, 5x GbE, OcteonTx Dual Core CPU
- Additional Ventana and Newport SBCs available in a variety of form factors and with up to 6x Mini-PCIe sites. See here for more information.
Recommended Mini-PCIe Cards for Wireless Support:
- GW16122 Sub-1GHz Radio – Based on Ti CC1352P Multiprotocol MCU
- GW16126 LTE CATM1 Cellular & BLE 5.0 Radio – Based on ublox SARA-R410 CATM1 Cellular Module and NINA-B301 BLE module (Nordic nRF52840 chipset)
- GW16130 Iridium SBD Satellite Radio – Based on Iridium 9603N SBD Module
- GW17032 802.11ac/abgn WiFi Radio – Based on Qualcomm QCA9880 Chipset, 3×3 MIMO
- GW17039 802.11bgn+BLE 4.0 Radio – Based on Qualcomm AR9565 Chipset
- GW17046 LTE CAT4 Cellular Radio – Based on ublox Toby-L2 Module
- Additional 3rd Party Radios are Available for Support of other Wireless Standards such as LoRa and SigFox.
