GW11036 Embedded Android Development Kit

An Embedded Android touchscreen LCD tablet development kit provides customer fastest time to market with lowest design risk.

** Not recommended for new designs. Please use the Venice Family of SBCs with Qt.

 Key Product Features
Function: Android Development System with 7in LCD Screen
Software: Android 5.1.1 Lollipop
Performance: Quad Core i.MX6 CPU & 1GB DRAM
Connectivity: WiFi, BLE, Ethernet, Opt. Cellular & Satellite
This standard model is available in any quantity.
Discounts offered on orders of 25/100/1k and higher.
See the "Ordering Options" tab for available configuration options.
To request pricing or discuss configuration options, please fill out the form below or send a message to
Street, City, State, Country EG: 103 Cypress St, Los Angeles, CA USA
Enter the model number that pricing is being requested for
Ensures Gateworks provides the best volume discount
  • Ventana GW5224 High Performance SBC
    • Freescale i.MX6 Quad Core Processor
    • 1GB DRAM
    • 2GB NAND Flash
    • GPS
    • WiFi and Bluetooth Radio
  • Android 5.1.1 Lollipop Preloaded on microSD
  • 7” TFT-LCD LVDS Panel (1024x600) with LED backlight and PCAP touchscreen
  • Black Annodized Aluminum Bezel Allows Quick Integration into Customer Enclosure
  • 802.11bgn + Bluetooth 4.0 + HS Radio with PCB Mount Antenna
  • 8GB microSD Flash Card – Class 10, UHS-1
  • LVDS Cable for Connecting Display to Single Board Computer
  • Fully integrated with Mounting Hardware
  • Includes GW5224 Development Kit Cables and JTAG Adapter
  • AC/DC 24V @ 1A Power Supply
Ordering Options

The GW11036 Android Development kit gives application developers a head start with Android Kit Kat on the Gateworks Ventana family of single board computers. The GW11036 development kit includes a 7-inch TFT-LCD PCAP touchscreen display mounted in an aluminum bezel, a microSD preloaded with Android Kit Kat, and a GW5224 single board computer with necessary accessories to begin development. The GW5224 SBC features the Freescale™ i.MX6 Quad Core CPU operating at 1GHz, 1Gbyte of DDR3-800 DRAM, 2Gbytes of System Flash, Ethernet, GPS, two Mini-PCIe sockets, HDMI and LVDS video outputs and and three analog video inputs. The Mini-PCIe expansion sockets support a combination of 802.11abgn/ac radios, LTE/4G/3G CDMA/GSM cellular modems and other PCI Express peripherals. The development kit also includes an 802.11bgn radio with both WiFi and Bluetooth support.
